XGIMI HORIZON 20

MSRP$1,699

XGIMI HORIZON 20 front three-quarter view, grey body with the lens at the top right and a Harman/Kardon speaker grille

Brand	XGIMI · HORIZON
Type	Home cinema
Released	October 2025
Resolution	4K UHD
HDR formats	HDR10+, Dolby Vision
Imaging technology	DLP
Light source type	RGB triple laser
ISO light output	3,200 lm
Throw ratio	1.2–1.5:1
Input lag (rated)	1920×1080 @ 240 Hz: 1 ms · 1920×1080 @ 120 Hz: 2.2 ms · 3840×2160 @ 60 Hz: 3 ms

A 4K DLP home projector with an RGB triple laser light source rated at 3,200 ISO lumens. It has Google TV, Harman/Kardon speakers, automatic setup (focus, keystone, screen alignment, obstacle avoidance) and gaming latency rated at 1 ms at 1080p 240 Hz. It suits living-room and casual home-cinema use, and a built-in stand lets it tilt up to the ceiling.

Data sheet


Imaging technology	DLP
Technology brand	DLP
Number of imaging devices	1
Chip / panel diagonal	0.47 in
Native aspect ratio	16:9
Addressable resolution	3840 × 2160
Dynamic contrast	20,000:1
BT.2020 gamut	110%
Gamut metric	Area
Bit depth / 'number of colours'	8 bit
Filmmaker Mode	Yes
HDR formats	HDR10+, Dolby Vision
Frame interpolation (MEMC)	Yes
Max refresh rate	1920×1080: 240 Hz
Input lag (rated)	1920×1080 @ 240 Hz: 1 ms · 1920×1080 @ 120 Hz: 2.2 ms · 3840×2160 @ 60 Hz: 3 ms Game Mode, auto keystone off (the PDF spec sheet adds VRR on)	Game Mode, auto keystone off (the PDF spec sheet adds VRR on)
Variable refresh rate	HDMI VRR
Auto low-latency mode	Yes
3D support	Yes

Optics

Throw ratio	1.2–1.5:1
Zoom type	Optical
Zoom ratio	1.25×Derived
Focus	Auto
Vertical lens shift	±120%
Horizontal lens shift	±45%
Motorized lens shift	Yes
Image size range	40–300 in

Light source

Light source type	RGB triple laser
Light source detail	RGB triple laser, with emission bands of 458-472 nm, 519-531 nm and 635-651 nm
ISO light output	3,200 lm ISO 21118	ISO 21118

Audio

Speaker power	24 W
Speaker count	2
Audio partner	Harman Kardon
DTS	Yes
Audio outputs	Optical, 3.5 mm, HDMI eARC
HDMI eARC	Yes

Inputs, control & connectivity

HDMI port count	2
HDMI ports (feature-level)	HDMI 1: HDMI, eARC; HDMI 2: HDMI
Wi-Fi	Wi-Fi 6
Bluetooth version	5.2
Auto keystone	Yes
Screen fit / alignment	Yes
Obstacle avoidance	Yes
Eye-protection sensor	Yes
Integrated stand / gimbal	Type: adjustable_stand

Firmware / software

Smart OS	Google TV
Casting	DLNA, Chromecast built-in
RAM	4 GB
Storage	128 GB
SoC	MT9679

Environment & power

Operating temperature	0–40°C
Operating orientations	Table, Ceiling, Rear
Rated voltage	100–240 V
Rated frequency	50–60 Hz
Power consumption (max)	180 W
Power supply	External brick
Fan noise (sound pressure)	Rated: 28 dB(A) 25°C ambient, 1 m from the machine	25°C ambient, 1 m from the machine
Noise measurement distance	1 m

Physical & installation

Width	298 mm
Depth	190 mm
Height	249 mm
Weight	4.8 kg

Support & ownership

Warranty	🇺🇸 US 2 yr · 🇬🇧 GB 2 yr · 🇪🇺 EU 2 yr Only the US page names HORIZON 20. The GB and EU pages state two years generally (the EU page: two years for laser projectors, one year for portable/home projectors), and HORIZON 20 is an RGB laser projector. Valid only in the country of purchase.
User manual	https://helpcenter.xgimi.com/hc/en-gb/article_attachments/50404742316697
Photobiological risk group	RG2
Safety & market certifications	IMAX Enhanced

In the box

Box contents	Power plug, User manual, Warranty card, Remote, Batteries
Remote type	Bluetooth
