ViewSonic LSD600W
| Brand | ViewSonic · Installation Projectors |
| Type | Installation |
| Released | May 2026 |
| Resolution | WXGA |
| Imaging technology | DLP |
| Light source | Laser (phosphor) |
| Brightness | 6,000 lm ANSI |
| Throw ratio | 1.18–1.54:1 |
A 1280x800 single-chip DLP laser projector for auditoriums, boardrooms and golf simulators, rated at 6,000 ANSI lumens with a 1.3x manual zoom lens and images up to 300 inches. It has two HDMI 1.4 inputs, RS-232 control, a 15 W mono speaker, DLP-Link 3D and a Golf mode, and no network port or Wi-Fi.
Data sheet
| White light output | 6,000 lm ANSI | |
| Claimed brightness (non-standard) | 6,600 lm (peak) | |
| Imaging technology | DLP | |
| Chip / panel diagonal | 0.65 in | |
| Native resolution | WXGA (1280 × 800) | |
| Native aspect | 16:10Derived | |
| Dynamic contrast | 3,000,000:1 | |
| Dynamic contrast method | Light-source dimming | |
| Colour bit depth (per channel) | 10 bit | |
| Colour management (CMS) | 6-axis | |
| 3D | Yes | |
| 3D glasses sync | DLP-Link |
Light source
| Light source | Laser (phosphor) | |
| Light-source life | 20,000 h normal · 30,000 h eco |
Optics
| Throw ratio | 1.18–1.54:1100″ · 2.54–3.32 m | |
| Image size | 30–300 in | |
| Projection offset | 124% | |
| Zoom | Optical | |
| Zoom ratio | 1.31×Derived | |
| Focal length | 16.9–21.61 mm | |
| Aperture (f-number) | 2.43–2.78 | |
| Focus | Manual | |
| Autofocus | No | |
| Vertical keystone | 30° | |
| Horizontal keystone | 30° | |
| Corner correction | 4-corner |
Motion & gaming
| Max input refresh | 720p: 120 Hz |
Inputs & control
| HDMI inputs | 2 × HDMI 1.4 (HDCP 1.4) | |
| Max input resolution | WUXGA | |
| USB media playback | No | |
| Control ports | RS-232 |
Smart platform
| Ethernet | No |
Audio
| Speaker power | 15 W | |
| Speakers | 1 | |
| Layout | Mono | |
| Audio outputs | 3.5 mm | |
| HDMI audio return | NoneDerived |
Physical & installation
| Dimensions (W × D × H) | 286 × 216 × 129 mm | |
| Weight | 2,900 g | |
| Orientations | Table, Ceiling, Rear, Portrait, 360° | |
| Ceiling mount | M4, screws ≤ 8 mm | |
| Sealed optical engine | Yes |
Environment & power
| Operating temperature | 0–40°C | |
| Operating humidity | 10–80%RH | |
| Altitude | 3,658 m · high-altitude mode | |
| Power draw | 163 W | |
| Standby | Up to 0.5 W | |
| Power supply | External adapter | |
| Mains input | 100–240 V · 50/60 Hz | |
| Fan noise | Normal 32 dB(A) · Eco 27 dB(A) |
Safety & support
| Laser class | Class 1 | |
| Risk group | RG2 | |
| Hazard distance | 1 m | |
| Marks | CE, FCC | |
| Warranty | 🇺🇸 US 3 yr | |
| User manual | viewsonicglobal.com |
In the box
| In the box | Power cord, Power adapter, Remote, Remote batteries, Quick start guide | |
| Remote | IR |
