InFocus INL3149WU

Brand	InFocus · INL3140 Series
Type	Business
Status	Discontinued
Released	September 2019
Resolution	WUXGA
Imaging technology	DLP
Light source	Laser (phosphor)
Claimed brightness (non-standard)	5,500 lm
Throw ratio	1.4–2.24:1

A single-chip DLP laser projector with a 0.67-inch WUXGA (1920x1200, 16:10) chip, a rated 5,500 lumens and a 1.6x manual zoom lens with manual vertical lens shift. It has HDMI 2.0, HDMI 1.4, two VGA inputs, HDBaseT, RJ45 and RS232, two 10 W speakers and a 30,000-hour laser light source.

Data sheet


Claimed brightness (non-standard)	5,500 lm
Brightness uniformity	85%
Imaging technology	DLP
Chip / panel diagonal	0.67 in
Native resolution	WUXGA (1920 × 1200)
Native aspect	16:10Derived
Colour wheel segments	4
3D	Yes
3D formats	Frame packing, Side-by-side, Top-bottom, Frame sequential
3D glasses sync	DLP-Link

Light source

Light source	Laser (phosphor)
Emitter	Blue laser + phosphor
Light engine	Quantum Color Engine
Light-source life	30,000 h
Light output control	Steps

Optics

Throw ratio	1.4–2.24:1100″ · 3.02–4.82 m
Image size	21–302 in
Projection offset	102%
Zoom	Optical
Zoom ratio	1.6×Derived
Focus	Manual
Autofocus	No
Vertical lens shift	-95–107%
Motorised lens shift	No
Auto keystone	Yes
Corner correction	4-corner

Inputs & control

HDMI inputs	HDMI 2.0 · HDMI 1.4
Other video inputs	VGA, Composite, HDBaseT
Max input resolution	DCI 4K
Audio inputs	3.5 mm, Microphone
Control ports	RS-232
Control-system drivers	Crestron, AMX

Smart platform

Ethernet

Yes

Audio

Speaker power	20 W
Speakers	2
Layout	Stereo
Audio outputs	3.5 mm
HDMI audio return	NoneDerived

Physical & installation

Dimensions (W × D × H)	374 × 302 × 117 mm
Weight	5,500 g
Orientations	Table, Ceiling, Rear
Ceiling mount	M6, screws ≥ 10 mm
Ingress protection	IP5X

Environment & power

Operating temperature	5–40°C
Operating humidity	10–85%RH
Altitude	3,048 m · high-altitude mode
Power draw	Max 341 W
Standby	Up to 0.5 W
Networked standby	Up to 2 W
Mains input	100–240 V · 50/60 Hz
Fan noise	27 dB(A)

Safety & support

Marks	CE, FCC, UL, KC
User manual	projectorcentral.com

In the box

Remote, Quick start guide, User manual, Warranty card, HDMI cable

Similar models

Model	Resolution	Tech	Lumens	Price
Christie LW551i WXGA · 3LCD	WXGA	3LCD	5,500	$5,985 +$2,976	Compare
Optoma ZH507+ 1080p · DLP	1080p	DLP	5,500	$4,369 +$1,360	Compare
Optoma ZH520 1080p · DLP	1080p	DLP	5,500*	$2,699 −$310	Compare
Optoma ZH521 1080p · DLP	1080p	DLP	5,500	—	Compare
Panasonic PT-VMW51 WXGA · 3LCD	WXGA	3LCD	5,200 −300	—	Compare
