NEC NP-PA622U

Brand	NEC · PA Series
Type	Installation
Status	Discontinued
Released	April 2014
Resolution	WUXGA
Imaging technology	3LCD
Light source	Lamp
Brightness	6,200 lm ISO
Throw ratio	1.5–3.02:1

A lamp-based 3LCD installation projector with a 1920x1200 (WUXGA) panel and a rated 6,200 lumens. It takes six interchangeable bayonet lenses and ships without one, has vertical and horizontal lens shift, and adds HDBaseT, DisplayPort, two HDMI inputs and an HDMI output. Edge blending, stacking and geometric correction support multi-projector installs.

Data sheet


White light output	6,200 lm ISO (Bright mode) · 6,200 lm ANSI (Bright mode) [PRESET] mode set to [HIGH-BRIGHT]; ECO MODE off	[PRESET] mode set to [HIGH-BRIGHT]; ECO MODE off
Brightness by mode	Max 6,200 lm · Eco 4,960 lm
Eco brightness	80%Derived
Imaging technology	3LCD
Chip / panel diagonal	0.76 in
Panel alignment	Whole-image
Native resolution	WUXGA (1920 × 1200)
Native aspect	16:10Derived
Dynamic contrast	6,000:1
Colour bit depth (per channel)	10 bit
Colour management (CMS)	6-axis
Picture mode memories	7
3D	Yes
3D formats	Frame packing, Side-by-side, Top-bottom
3D glasses sync	RF

Light source

Light source	Lamp
Lamp power	350 W
Replacement lamp	NP26LP
Light-source life	3,000 h normal · 4,000 h eco
Light output control	Steps

Optics

Throw ratio	1.5–3.02:1100″ · 3.23–6.50 m
Image size	30–500 in
Zoom	Optical
Zoom ratio	2.01×Derived
Focus	Manual
Autofocus	No
Vertical lens shift	-10–50%
Horizontal lens shift	±30%
Motorised lens shift	No
Vertical keystone	40°
Horizontal keystone	40°
Grid warp	Yes
Interchangeable lens	Yes

Inputs & control

HDMI inputs	2 × HDMI
Other video inputs	VGA, HDBaseT
Max input resolution	DCI 4K
Audio inputs	3.5 mm
USB media playback	Yes
Control ports	RS-232, Wired IR
PJLink	Class 1
Control-system drivers	Crestron

Smart platform

Ethernet

Yes

Audio

Speaker power	10 W
Speakers	1
Layout	Mono
Audio outputs	3.5 mm
HDMI audio return	NoneDerived

Physical & installation

Dimensions (W × D × H)	499 × 359 × 142 mm
Weight	8,400 g
Orientations	Table, Ceiling, Rear, Portrait, 360°
Dust filter	Replaceable

Environment & power

Operating temperature	5–40°C
Operating humidity	20–80%RH
Altitude	3,650 m · high-altitude mode
Power draw	Max 483 W · Normal 460 W · Eco 362 W
Standby	0.16 W
Networked standby	7.9 W
Mains input	100–240 V · 50/60 Hz
Fan noise	Normal 39 dB(A) · Eco 33 dB(A)

Safety & support

Marks	CE
Warranty	🇪🇺 EU 3 yr (light source 6 mo or 1,000 h) · 🇺🇸 US 3 yr The 2014 US press release says the lamp is covered for 1 year or 500 hours, whichever comes first.
User manual	sharp-nec-displays.com

In the box

In the box	Power cord, Remote, Remote batteries, Quick start guide, Lens cap, Software CD
Remote	IR

Similar models

Model	Resolution	Tech	Lumens	Price
Panasonic PT-RZ660 WUXGA · DLP	WUXGA	DLP	6,000 −200	$4,292.34 −$2,307	Compare
InFocus IN1048SL 1080p · DLP	1080p	DLP	6,000 −200	$2,093.10 −$4,506	Compare
Panasonic PT-FRQ60 4K UHD · DLP	4K UHD	DLP	6,000 −200	$6,299.99 −$299	Compare
Sharp XP-P601Q-W 4K UHD · DLP	4K UHD	DLP	6,000 −200	$4,765.93 −$1,833	Compare
Sony VPL-PHZ61 WUXGA · 3LCD	WUXGA	3LCD	6,400 +200	$3,266.95 −$3,332	Compare
BenQ AK900ST 4K UHD · DLP	4K UHD	DLP	6,000 −200	$5,999 −$600	Compare
